GM MDI is a new GM Diagnostic tool.it is not only work for the new gm car,but also for the old kind of car.it can test GM car from 1990---2012 year gm car. We can supply tech win and gds2 software for you.
GM MDI (Multiple Diagnostic Interface) for wireless ECU reprogramming utilizing J2534.
The GM MDI is initially being introduced with Pass-Thruprogramming capabilities only. It can be used to perform Pass-Thru programming on all vehicles built since 1993 and willsupport all vehicles into the future.The GM MDI will be required to perform diagnostics onselected NAO vehicles for model year 2009. Diagnostic soft-ware is scheduled to be released for the GM MDI during thefourth quarter of 2008.
When diagnostics are introduced, the MDI will also get a remote data record capability. This permits recording data duringa road test, similar to the Tech 2 Snap Shot function. A trigger switch connector is provided for this purpose. Regulations require programming procedures to be compliantwith SAE Recommended Practice J2534. The GM SPS is com-pliant with SAE Recommended Practice J2534, and the GMMDI is compliant with the portions of SAE J2534 that areapplicable for GM vehicles.
GM MDI Interface Description
The MDI is used by professional technicians as an aid in diagnosing and repairing automotive electrical and electronic systems. The MDI is designed to connect the vehicle to a TIS 2 Web PC computer application which then functions though the MDI for data transfer and Electronic Control Unit (ECU) reprogramming. See Figure IV-2 for the location of the connectors and indicators (LEDs) on the MDI.
Connectors and Indicators (LEDs) on the MDI
Host Computer Interface
Using the PC application MDI Manager software, you configure the MDI to communicate with a host computer. The MDI is capable of communicating over a USB cable, an ethernet cable (LAN), or wireless (WLAN),PC Connections on the MDI
Packet list:
1: GM MDI
2: J1962 Diagnostic connector
3: USB cable
4: Internet cable
5: AC adapter /power supply
6: Wireless interface
7: Owner manual
FAQ:
1:Why do you order GM MDI from our company ?
1): good quality gm mdi.not only for the diagnostic function but also programmer function.bad gm mdi is cheaper and can not do programmer function.
2): 2 year warranty.for our good quanlty and use all new chip. for the different with bad quanlity one, you can check the compare photo follow.
3): good software for you. GM tech2win and GDS2 software. Opel diagnotic+programmer software.Europe Chavlet diagnotic+programmer software.
4): activate software offline.
2: MDI : good or bad quality ?
Every client want to get best quality gm mdi even it will take little more money. But some client order some cheap GM MDI and test it , so much problem. For example : can not program, bad quality, easy broken ,no wifi function, can not work original software…
3: So how to check the best quality of GM MDI ?
1): Wifi function. Bad quality GM MDI have not WIFI function.
2): Work with original software. Bad quality cannot work with original software
3): Programmer function good . Bad quality cannot do programmer function.
4): Warranty time. Good quality warranty 2 years.
5): The most important: Bad quality use old chip and short of many kind of chip.
What kind of software we can supply ?
1.We can provide the tech2win software for the before 2009.6 year car (GM, OPEL,Chavelet,SAAB car)
2. We can provide the GDS2 software for the after 2009.6 year car (GM, OPEL,Chavelet,SAAB car)
3.We can provide the Globaltis sps software for the programmer function and activate tech2wiin and gds2 function (OPEL,Chavelet), you can use it activate the GDS2 and Tech2win software.
